When upper cabinets are too high, reaching for a deep bowl requires standing on tiptoes; or to find a plate, you have to move all the bowls in front of it out of the way. While traditional bowl racks solve some storage issues, in real-world use, they still suffer from awkward access, poor space utilization, and a tendency to jam over time.



Now, an increasing number of modern kitchens are adopting motorized adjustable bowl rack solutions. Compared to traditional fixed bowl racks, these systems use an electric lifting mechanism to slowly lower the rack to a more ergonomic height for use, then retract it back into the wall cabinet afterward. This keeps the kitchen looking tidier and eliminates the inconvenience of frequent bending and tiptoeing.



For kitchens with tall cabinets, minimalist kitchens, and smart home projects, this concealed design is gradually becoming a new trend in storage.







This Kitchen Bowl Rack features a built-in design, installed entirely within the wall cabinet. When closed, only the uniform cabinet door is visible from the outside, preserving the kitchen's overall aesthetic.

Compared to traditional exposed bowl racks, it is better suited for modern minimalist styles, stone-countertop kitchens, and high-end custom cabinetry projects.

In practice, users simply need to lightly press a button, and the bowl basket will slowly descend to the work area. Once items have been retrieved, another touch will cause it to automatically rise back up.

The entire lifting process is smoother, reducing the clattering and shaking caused by the frequent opening and closing of traditional pull-out baskets.



 Compatible Cabinet Dimensions

 External width: 600 / 700 / 800 / 900 mm

 Cabinet Depth: ≥312 mm

Currently compatible with most standard wall cabinet dimensions.





For construction projects, custom cabinets, or kitchens with special dimensions, we also support customization for non-standard sizes, including:

 Cabinet width adjustments

 Color schemes such as dark gray or black

 Load-bearing capacity upgrades

 Expanded smart control features

Ideal for integrated smart kitchens or high-end residential projects.



Project	Parameter
Load Capacity	20 kg
Descent Time	Approx. 8 seconds
Input Voltage	100–240 V (wide voltage range, worldwide compatibility)
Rated Power	96W
Output voltage	24V (safety low voltage)
Lighting position	Rear (auxiliary lighting, for easy bowl retrieval in low light)
Light color temperature	4000K (natural white light, non-glare)
Motor Noise Level	≤45 dB (Quiet)
Fatigue Test	30,000 normal lifts (equivalent to 8 lifts per day, with a service life of over 10 years)
Body Material	Aviation-grade aluminum alloy



The 30,000-cycle fatigue test data is primarily used to simulate long-term daily usage conditions. Under normal household usage frequency, it can meet long-term, stable lifting and lowering needs.



The body features an aerospace-grade aluminum alloy structure, which is better suited for the humid kitchen environment compared to standard iron hardware and reduces the risk of rust after long-term use.







In addition to basic touch-controlled lifting, this product supports a variety of smart expansion options.

Depending on project requirements, the following options are available:

 Voice Control: Say "Hey, Angel, lower" to a smart speaker, and it will automatically lower.

 Remote Control Operation: Mount it on the wall or hold it in your hand to raise or lower the unit without reaching out to touch it.

 Tuya Smart Integration: Control remotely via a mobile app or link with other smart devices (e.g., set "Cooking Mode" to automatically lower the dish rack).

All upgrade features are customizable options that can be added as needed, allowing you to easily create your own personalized smart kitchen.







Traditional dish racks focus more on basic storage, while electric lift systems prioritize the "user experience." Their advantages are particularly evident in the following scenarios:

 Highly positioned wall cabinets

 Small apartments requiring improved space utilization

 Minimalist kitchens aiming to minimize visible storage

 High-end custom projects emphasizing smart experiences

 Households with elderly members seeking to minimize bending and tiptoeing

Additionally, for cabinet brands, project procurement clients, and smart home integrators, stability and after-sales support are equally important.



Current product support:

 OEM / ODM Customization

 Logo Customization

 Project-specific feature adjustments

 Bulk project supply

We also provide installation guidance, product testing documentation, and relevant test reports.







Before installation, we recommend confirming the following two basic dimensions:

 Cabinet exterior width: 600–900 mm

 Cabinet depth: ≥312 mm

For wall cabinets with special configurations, we recommend providing cabinet dimension drawings in advance to confirm the installation space.





FAQ

This Kitchen Bowl Rack is ideal for modern kitchens, minimalist kitchens, high-end custom kitchens, and smart home projects. It is especially suitable for homes with high wall cabinets where traditional dish racks are difficult to access.

Yes, we offer full OEM/ODM customization services. Whether it's dimensions, colors, logos, or functional configurations, we can tailor the product to your specific needs. We also provide exclusive smart control upgrade services for brand owners, cabinet manufacturers, smart home projects, and commercial procurement clients to meet diverse project requirements.

The product is shipped as a complete unit, and the installation steps are simple. We also provide installation guidance, a user manual, and video tutorials to help you complete the installation quickly.
